Feature
◎Suitable for the metering and packaging of pastes and liquids like tomato sauce, curry sauce, sesame paste, oil sachets, vinegar sachets, and chili oil.
◎All the works of bag making,measuring, filling,sealing, cutting and counting can be done automatically,at the same time,it can also according to the demand of customers printing batch number and other functions.
◎The touch screen operation, PLC contro,servo motor to control the bag length,stable performance,easy to adjust and accurate detection.Choose the intelligent temperature controller and PID control to ensure the error range of temperature controlled within 1 degree Centigrade.
◎Packaging materials:composite film
◎All the works of bag making,measuring, filling,sealing, cutting and counting can be done automatically,at the same time,it can also according to the demand of customers printing batch number and other functions.
◎The touch screen operation, PLC contro,servo motor to control the bag length,stable performance,easy to adjust and accurate detection.Choose the intelligent temperature controller and PID control to ensure the error range of temperature controlled within 1 degree Centigrade.
◎Packaging materials:composite film
Machine Running Video:
Application
◎ Applicable Bag Type: three-side seal bag, four-side seal bag etc.
◎ Applicable Film Material: a variety of laminated films, single layer PE film. Film thickness range 0.03~0.10mm.
◎ Applicable Packing Materials: a variety of liquid&sauce, like honey, tomato sauce, butter, chocolate sauce, cream, jam etc.
| Model | LKHS-320L | |
| Bag Length | 30-180mm | |
| Bag Width | 35-100mm | |
| Suitable Bag Material | OPP,CPP,PA/PE,PP/CPP,PET/PE,Laminated | |
| Suitable Bag Style | 3-side, 4 side sealing bag, stand-up bag, handbag, spout bags, zipper bag, compound bag,etc. | |
| Air supply | 0.4-0.6 MPa | |
| Packing speed | 60-120 bags/min (Depend on materials and weight) | |
| Power | AC220V or AC 380V 2KW-6KW | |
| Machine Size | 1500*500*1900mm | |
| Weight | About 400kg | |
