Feature
◎Application: Screw, bolt, washer, nut and other kinds of regular shape fastener products.
◎Adopting spacking counting and fiber optics re-inspection or completed fiber optics counting, suitable to mixing packaging for 1~50 varieties of items.
◎Solid sealing, smooth and elegant bag shape; high efficiency and durability, can be equipped with exhaust device, printer,labeling machine, transfer conveyor and weight checker.
◎Automatic ordering, counting, packing and printing etc. Easily adjust the quantity of screws in the bag, set the quantity of bags what you need, when meet, the machine will be stop automatically.
Machine Running Video:
Specification:
◎ Applicable Bag Type: pillow bag, four-side seal bag, three-side seal bag, gusset bag.
◎ Applicable Film Material: a variety of laminated films, single layer PE film. Film thickness range 0.03~0.10mm.
| Model | LK-300H | LK-400H | LK-500H | LK-600H |
| Bag Length | L: 50-180mm | L: 80-250mm | L: 100-180mm | L: 100-400mm |
| Bag Width | W: 40-140mm | W: 40-190mm | W: 90-240mm | W: 100-300mm |
| Max film width | 300mm | 400mm | 500mm | 600mm |
| Packing material | OPP, CPP, PA/PE, PP/CPP, PET/PE, Laminated film | |||
| Air supply | 0.4-0.6 MPa | |||
| Packing speed | 10-50 bag/min (Depend on the counting quantity and material size) | |||
| Power | AC220V or AC 380V 2KW-6KW | |||
| Machine Size | Customized | |||
Application:
Hardware Parts: nuts bolts joint, nuts, bolts, screws, pins, steel nails, washers, rivets, fasteners, etc.
Rubber Parts/Plastic Parts: wall anchors, O-rings, pipe clips, rubber housing, molded parts, etc.
Furniture Hardware: furniture connectors, furniture fasteners, furniture fittings, furniture accessories, cabinet hardware, door hardware, lock hardware, hinge hardware.
Toys: small rubber toys, LEGO building bricks, dice, etc.
Foods & Pills: tablet capsule, effervescent tablet, milk tablet, jelly beans, sugar-coating tablet, non-sticky Candies, etc.
Others: kitchen hardware, bike hardware, computer hardware, electronic hardware parts, etc.
