LKV-420Y Snack Nuts Cookies Packaging Machine
LKV-420Y Snack Nuts Cookies Packaging Machine
Contact Us
Common Output

✅ MIAN FEATURES

  1. Multihead Weigher Precise Weighing: 10/14 head combination weigher, high weighing accuracy for irregular shape snacks.
  2. Nitrogen Gas Flushing System: Inject nitrogen into bags to prevent oxidation, keep potato chips crisp.
  3. 304 Stainless Steel Structure: Food contact part stainless steel, easy to clean, corrosion resistant.
  4. Z-type Bucket Elevator: Gentle material conveying to avoid breaking fragile chips and puffed snacks.
  5. PLC & Touch Screen Operation: Easy parameter setting, save multiple product recipes, quick product switch.
  6. Servo Film Pulling: Stable bag forming, less film waste, low maintenance cost.

✅RUNNING VIDEO

Heat‐sealing and microscopic evaluation of paper‐based coated materials using various seal bar geometries in vertical form fill seal machine - Merabtene - 2023 - Packaging Technology and Science - Wiley Online Library

✅ APPLICATION

◎ Applicable Bag Type: pillow bag, gusset bag, quadro bag, four-side seal bag, three side seal bag, triangle bag.
◎ Applicable Film Material: a variety of laminated films, single layer PE film. Film thickness range 0.03~0.15mm.
◎ Applicable Packing Materials: a variety of snack food,frozen food, detergent powder, pet food, coffee, oatmeal, sugar, salt, puffed food, rice, herbal,tea, small hardware, etc.

Model LKV-420 LKV-520 LKV-720 LKV-900 LKV-1050 LKV-1200
Film Thickness(mm) 0.04-0.08 0.04-0.12 0.04-0.12 0.04-0.12 0.04-0.12 0.04-0.12
Bag Length (mm) 80-300 80-350 100-500 100-600 100-800 100-1000
Bag Width (mm) 60-200 100-250 180-350 260-430 290-505 290-580
Film Roll Diameter

(mm)
Max.320 Max.320 Max.320 400 400 400
Packaging Rate

(bags/min)
5-60 5-60 5-55 5-20 5-20 5-20
Film Width (mm) Max.420 Max.520 Max.720 Max.900 Max.900 Max.1200
Measurement


Range
150-1500ml 5-2000ml 4000ml 1-25L 1-25L 1.5L-45L

✅ FAQ

Q: Can this vertical packing machine pack potato chips?

A: Yes, this VFFS machine is specially designed for potato chips, ripple chips and other fragile snacks. It can equip nitrogen flushing system to keep chips crispy.

Q: What kind of bags does this machine make?

A: It makes pillow bags, bag width and length can be adjusted.

Q: Is the machine stainless steel?

A: Food contact parts are 304 stainless steel, meet food industry standard.
