Feature
◎ PLC control, man machine interface, easy to operate and maintain.
◎ Equipped with servo motor and optical tracking device to keep accuracy and high speed.
◎ Automatic multihead weighing and packing combined design, saving room space and reduce the investment cost.
Machine Running Video:
Application
◎ Applicable Bag Type: pillow bag, gusset bag, seal type bag, triangle bag.
◎ Applicable Film Material: a variety of laminated films, single layer PE film. Film thickness range 0.03~0.15mm.
◎ Applicable Packing Materials: a variety of powder, like flour, milk powder, baking powder, coffee powder, cocoa powder, starch powder, protein powder and seasoning powder and other fine powder products.
| Model | LKV-420 | LKV-520 | LKV-720 | LKV-900 | LKV-1050 | LKV-1200 |
| Film Thickness(mm) | 0.04-0.08 | 0.04-0.12 | 0.04-0.12 | 0.04-0.12 | 0.04-0.12 | 0.04-0.12 |
| Bag Length (mm) | 80-300 | 80-350 | 100-500 | 100-600 | 100-800 | 100-1000 |
| Bag Width (mm) | 60-200 | 100-250 | 180-350 | 260-430 | 290-505 | 290-580 |
| Film Roll Diameter (mm) |
Max.320 | Max.320 | Max.320 | 400 | 400 | 400 |
| Packaging Rate (bags/min) |
5-60 | 5-60 | 5-55 | 5-20 | 5-20 | 5-20 |
| Film Width (mm) | Max.420 | Max.520 | Max.720 | Max.900 | Max.900 | Max.1200 |
| Measurement Range |
150-1500ml | 5-2000ml | 4000ml | 1-25L | 1-25L | 1.5L-45L |
